Conveyorised Plate Curing Machine
Description :
suitable for baking ctp / ctcp / conventional ps plates:-
“Memory” plate curing machine is designed to bake ctp / ctcp / conventional ps plates
Simple & easy control panel includes main on/off, digital temperature meter with thermostat, led display for heaters & variable ac drive.
The machine is specially designed and is completely insulated thus saves heat loss and avoids hot air in the surrounding working areas.
Thermostatically controlled hot air maintains inside temperature evenly, thus ensure even baking at a temperature ranging form 220°c to 250°c.
Sturdy aluminum profile structure with built - in coater for baking solution application & in line wash / gum / dry unit eliminates skilled
Labour requirement thus ensures dry plates ready for press use
Baking helps to give long print runs with same sharpness thus ensures smooth running on press and easy to store plates for repeat jobs.
The unit can be attached with conveyor bridge to the ctp processor for in-line working.
The in-line process avoids direct contact of heat with the operator thus makes it user & operation friendly.
