Salient Features :

• Optimal solution to double-side lamination in single pass
• Advantageous for digital / offset press for short batch production

FEEDER :

• Manual feeding

OPTIONAL UPGRADE : INTEGRATED IN-LINE SHEETER

• Pneumatically controlled in-feed Nip Rollers for precision sheeting
• Thermal in-line sheeting (130 g/m² - 450 g/m² )
• Sheet counter with digital display
• Reception / Collection unit

TECHNICAL SPECIFICATIONS

Feeding	Manual
Paper Stock	90 - 450 g/m²
Laminating Speed (Thermal)	0 - 25 m/min*
Laminating Pressure	Hydraulic
Temperature band	80 - 130º C
Power X OPV	6.5 kW X 415 v X 50 Hz

* Production speed is subject to substrate and operating parameters

STANDARD SIZE :

MM	400	450	500	600
Inches	16"	18"	20"	24"
